7075 Aluminum Plate

Phone ：+ 86 19563413328

WhatsApp ：+ 86 19563413328

Email ：sales@xingyuegroups.com

PRODUCT PARAMETERS

7075 ALUMINUM PLATE

7075 aluminum plate is a cold-treated forged alloy with high strength and hardness, far superior to mild steel. 7075 aluminum plate is one of the strongest commercial alloys, with general corrosion resistance, good mechanical properties and anodic reaction. Fine grains make deep drilling performance better, tool wear resistance enhanced, thread rolling more unique, and the preferred metal material when density requirements are small and hardness requirements are relatively high.

PRODUCT USE

It is used to manufacture aircraft structures and other high-stress structural parts that require high strength and strong corrosion resistance, such as upper and lower wing panels, trusses, bulkheads, etc. After solution treatment, it has good plasticity and particularly good heat treatment strengthening effect. It has high strength below 150℃ and particularly good low-temperature strength. It has poor welding performance and a tendency to stress corrosion cracking. Double-stage aging can improve SCC resistance. Provided by Wuxi Hanshin Metallurgy.

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others: Each	Others: Total	Al: Min.
1050	0.25	0.4	0.05	0.05	0.05	-	0.05	0.03	0.03	-	99.5
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	0.03	-	99.6
1070	0.2	0.25	0.04	0.03	0.03	-	0.04	0.03	0.05	-	99.7
1100	0.95 Si + Fe		0.05~0.20	0.05	-	-	0.1	-	0.05	0.15	99
2014	0.5~1.2	0.7	3.9~5.0	0.4~1.2	0.2~0.8	0.1	0.25	0.15	0.05	0.15	margin
2017	0.2~0.8	0.7	3.5~4.5	0.4~1.0	0.4~0.8	0.1	0.25	0.15	0.05	0.15	91.5 - 95.5
2024	0.5	0.5	3.8~4.9	0.3~0.9	1.2~1.8	0.1	0.25	0.15	0.05	0.15	margin
3003	0.6	0.7	0.05~0.20	1.0~1.5	-	-	0.1	-	0.05	0.15	margin
3A21	0.6	0.7	0.2	1.0-1.6	0.05	-	0.15	0.1-0.2	-	-	margin
3004	0.3	0.7	0.25	1.0~1.5	0.8~1.3	-	0.25	-	0.05	0.15	margin
3005	0.6	0.7	0.3	1.0~1.5	0.2~0.6	0.1	0.25	0.1	0.05	0.15	margin
3105	0.6	0.7	0.3	0.3~0.8	0.2~0.8	0.2	0.4	0.1	0.05	0.15	margin
5005	0.3	0.7	0.2	0.2	0.5~1.1	0.1	0.25	-	0.05	0.15	margin
5052	0.25	0.4	0.1	0.1	2.2~2.8	0.15~0.35	0.1	-	0.05	0.15	margin
5754	0.4	0.4	0.1	0.5	2.6~3.6	0.3	0.2	0.15	0.05	0.15	margin
5A05	0.5	0.5	0.1	0.3-0.6	4.8-5.5	-	0.2	-	0.05	0.05	margin
5083	0.4	0.4	0.1	0.4~1.0	4.0~4.9	0.05~0.25	0.25	0.15	0.05	0.15	margin
6061	0.40~0.8	0.7	0.15~0.4	0.15	0.8~1.2	0.04~0.35	0.25	0.15	0.05	0.15	margin
6082	0.70~1.3	0.5	0.1	0.4~1.0	0.6~1.2	0.25	0.2	0.1	0.05	0.15	margin
7075	0.4	0.5	1.2~2.0	0.3	2.1~2.9	0.18~0.28	5.1~6.1	0.2	0.05	0.15	margin

FACTORY DISPLAY

COMPANY INTRODUCTION

Shandong Xingyue Materials Co., Ltd

Shandong Xingyue Materials Co.,Ltd. is a professional supplier of steel and metal raw materials. Its main products include carbon steel, copper, stainless steel, profiles, rare materials and other products. It is a comprehensive manufacturer. Its products are used in construction, home appliances, aerospace and other fields. The company has strong technical strength and advanced process equipment.

Shandong Xingyue Materials Co.,Ltd. has been recognized by the industry for its integrity, strength and product quality, and its products are sold to many regions at home and abroad. The company adheres to the purpose of "winning customers' trust with quality and expanding the market with reputation" and the development concept of "trust first, humility as sincerity, and harmony as precious", and has won the trust of customers. We are dedicated to providing excellent products and services to customers at home and abroad, and work together for development!
