TITANIUM ROD

Titanium is a new type of metal, known for its high strength-to-weight ratio. It is a low-density, strong metal with strong ductility (especially in an oxygen-free environment), lustrous, and metallic white in color.

The properties of titanium are related to the impurity content of carbon, nitrogen, hydrogen, oxygen, etc. The purest titanium iodide has an impurity content of no more than 0.1%, but its strength is low and its plasticity is high. The properties of 99.5% industrial pure titanium are: density ρ=4.5g/cm3, melting point 1725℃, thermal conductivity λ=15.24W/(m.K), tensile strength σb=539MPa, elongation δ=25%, cross-sectional shrinkage ψ=25%, elastic modulus E=1.078×105MPa, hardness HB195.

MEDICAL TITANIUM ROD

Specifications: rolled ￠8.0---40mm× L; forged ￠40---150mm×L

Metallurgical structure: pure titanium grain size is not less than grade 5, TC4 titanium alloy meets A1-A9.

Surface: black leather surface, polished surface, polished surface (H11, H9, H8)

Performance of medical titanium rod (reference implementation standard: GB/T13810-2007, ASTM F67/F136).

PRODUCT USE

1) Orthopedic implants: artificial joints, metal plates, bone nails, metal orthopedic rods, intramedullary nails, bone needles, spinal fixation devices.

2) Cardiac drug implants: artificial heart valves, pacemakers, cardiac catheters and intravascular stents.

3) Ophthalmic implants: artificial lenses.

4) Dental implants: dental implants, traction nails, nail plant root canals, internal fixation devices, etc.

5) Filling materials: breast fillers, intraocular fillers, orthopedic fillers.
